Reliable NAND Flash Memory Controllers for CF/ PATA based Industrial Storage Solutions
CompactFlash & Parallel ATA Controller for Card Solutions & Embedded IDE and Disk on Module SolutionsCompact Flash was the standard industrial interface for many years and delivered long lasting products in a mature form factor. Hyperstone is committed to supporting this interface. Even though it is widely understood as a legacy interface, Compact Flash is still a valid alternative for many systems and maintains a strong footing across a range of markets. The foundations of automation equipment still require a high volume of CF. Compact Flash is also used in 3G base stations, Cashier Systems and Electronic Gaming.

F9
Industrial CompactFlash, CF card and PATA Solid State Disk (SSD) controller- Designed to fully satisfy industrial reliability, endurance, and feature requirements
- hyReliability™ Flash Management including superior wear leveling, read disturb management, and power fail management ensuring highest reliability and durability
- hyMap® Flash Translation Layer (FTL) offering second to none random write performance, minimal write amplification, and consequently highest endurance for random access heavy usage profiles
- Flexible 96-Bit/1K BCH ECC engine supporting all Flash Memory requirements
- Optimized 32-Bit RISC core, extended instruction set for Flash Memory handling
- Continuously updated Flash Memory chip support and long term availability
- High performance on-the-fly AES 128 and 256 encryption engine
- Custom features can be implemented with simple firmware upgrades
- Turnkey solution including firmware, manufacturing kit, test and development hardware, as well as reference schematics
- 16 GPIOs for customer specific applications supporting SPI, I2C and ISO7816 or additional flash CE
- Application Programming Interface (API) and Software Development Kit (SDK) to develop own Custom Firmware Extensions (CFE)
